TECHNICAL SPECIFICATIONAE 2420ZK-SR

PRINCIPAL DIMENSIONS - MM

A: 204 mm.
B: 265 mm.
C: 155 mm.
D: 165 mm.
E: 102 mm.

HERMETIC COMPRESSOR AE 2420ZK-SR

BOM ID : 17B-A0

Electrical : 220-240 Volt 50 Hz 1 Phase 480 / 498 HP

View Full Information : PDF Download

Nominal Performance

Cooling Capacity
480 / 498 Watts
1,638 / 1,699 BTU/Hr
413 / 428 Kcal/Hr
Power Input
356 / 370 Watts
Lock Rotor Amps
11 / 11 Amps
Max Continuous Current
- / - Amps
Rated Load Amps
2 / 2 Amps
COP
1 / 1 Watts / Watts

Testing Conditions

Condensing Temperature
54.40 °C 129.92 °F
Evaporating Temperature
-23 / - °C -10 / - °F
Liquid Temperature
32.20 °C 89.96 °F
Return Gas Temperature
32.20 °C 89.96 °F
Ambient Temperature
32.20 °C 89.96 °F

Application

Evaporating Range
LBP
: -40.00 °C to -12.20 °C (-40.00 F to 10.04 °F)
Heat Pump
: - to - (- to -)
