TECHNICAL SPECIFICATIONWJ 26MHG-3
PRINCIPAL DIMENSIONS - MM
A: 264 mm.
B: 223 mm.
C: 203 mm.
D: 122 mm.
E: 239 mm.
HERMETIC COMPRESSOR WJ 26MHG-3
BOM ID : 75L-A0
Electrical : 240 Volt 50 Hz 1 Phase 2,150 / 3,950 HP
View Full Information :
PDF Download
Nominal Performance
Cooling Capacity
2,150 / 3,950 Watts
7,336 / 13,477 BTU/Hr
1,849 / 3,397 Kcal/Hr
Power Input
1,246 / 1,550 Watts
Lock Rotor Amps
38 / 38 Amps
Max Continuous Current
11 / 11 Amps
Rated Load Amps
6 / 7 Amps
COP
2 / 3 Watts / Watts
Testing Conditions
Condensing Temperature
54.40 °C
129.92 °F
Evaporating Temperature
-7 / 7 °C
20 / 45 °F
Liquid Temperature
46.10 °C
114.98 °F
Return Gas Temperature
35.00 °C
95.00 °F
Ambient Temperature
35.00 °C
95.00 °F
Application
Evaporating Range
MBP/HBP
: -15.00 °C to 10.00 °C (5.00 F to 50.00 °F)
Heat Pump
: - to - (- to -)
